Android – GridView example

By -
Problem: Simple GridView example
Description:

What do you say, is this simple GridView example?, I think it is not :) :). The main purpose of this post is to give demo for creating nicely laid GridView and also to make GridView more fancy.

Same as previous Android – ListView articles, we are going to create custom adapter for the GridView. I assume you are already aware of this or you have learnt it from my previous articles, If you aren’t aware about this then you should go through the previous article of Android – ListView.

And for understanding GridView XML layout attributes, just go through this article: Android – GridView – 1001 attributes to keep in mind

FYI, I have also attached example file for the easier download and implementation, example zip file is with full code (total 4 main files including 2 class files and 2 xml layout files).

Output ScreenShots:

Android GridView example

Android - GridView example

Solution:
GridViewExampleActivity.java
package com.technotalkative.gridviewexample;

import java.util.ArrayList;

import android.app.Activity;
import android.os.Bundle;
import android.view.View;
import android.widget.AdapterView;
import android.widget.GridView;
import android.widget.Toast;
import android.widget.AdapterView.OnItemClickListener;

public class GridViewExampleActivity extends Activity {
    /** Called when the activity is first created. */

	private GridviewAdapter mAdapter;
	private ArrayList<String> listCountry;
	private ArrayList<Integer> listFlag;

	private GridView gridView;

    @Override
    public void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.main);

        prepareList();

        // prepared arraylist and passed it to the Adapter class
        mAdapter = new GridviewAdapter(this,listCountry, listFlag);

        // Set custom adapter to gridview
        gridView = (GridView) findViewById(R.id.gridView1);
        gridView.setAdapter(mAdapter);

        // Implement On Item click listener
        gridView.setOnItemClickListener(new OnItemClickListener()
        {
			@Override
			public void onItemClick(AdapterView<?> arg0, View arg1, int position,
					long arg3) {
				Toast.makeText(GridViewExampleActivity.this, mAdapter.getItem(position), Toast.LENGTH_SHORT).show();
			}
		});

    }

    public void prepareList()
    {
    	  listCountry = new ArrayList<String>();

    	  listCountry.add("india");
    	  listCountry.add("Brazil");
          listCountry.add("Canada");
          listCountry.add("China");
          listCountry.add("France");
          listCountry.add("Germany");
          listCountry.add("Iran");
          listCountry.add("Italy");
          listCountry.add("Japan");
          listCountry.add("Korea");
          listCountry.add("Mexico");
          listCountry.add("Netherlands");
          listCountry.add("Portugal");
          listCountry.add("Russia");
          listCountry.add("Saudi Arabia");
          listCountry.add("Spain");
          listCountry.add("Turkey");
          listCountry.add("United Kingdom");
          listCountry.add("United States");

          listFlag = new ArrayList<Integer>();
          listFlag.add(R.drawable.india);
          listFlag.add(R.drawable.brazil);
          listFlag.add(R.drawable.canada);
          listFlag.add(R.drawable.china);
          listFlag.add(R.drawable.france);
          listFlag.add(R.drawable.germany);
          listFlag.add(R.drawable.iran);
          listFlag.add(R.drawable.italy);
          listFlag.add(R.drawable.japan);
          listFlag.add(R.drawable.korea);
          listFlag.add(R.drawable.mexico);
          listFlag.add(R.drawable.netherlands);
          listFlag.add(R.drawable.portugal);
          listFlag.add(R.drawable.russia);
          listFlag.add(R.drawable.saudi_arabia);
          listFlag.add(R.drawable.spain);
          listFlag.add(R.drawable.turkey);
          listFlag.add(R.drawable.united_kingdom);
          listFlag.add(R.drawable.united_states);
    }
}
GridviewAdapter.java
package com.technotalkative.gridviewexample;

import java.util.ArrayList;
import android.app.Activity;
import android.view.LayoutInflater;
import android.view.View;
import android.view.ViewGroup;
import android.widget.BaseAdapter;
import android.widget.ImageView;
import android.widget.TextView;

public class GridviewAdapter extends BaseAdapter
{
	private ArrayList<String> listCountry;
	private ArrayList<Integer> listFlag;
	private Activity activity;

	public GridviewAdapter(Activity activity,ArrayList<String> listCountry, ArrayList<Integer> listFlag) {
		super();
		this.listCountry = listCountry;
		this.listFlag = listFlag;
		this.activity = activity;
	}

	@Override
	public int getCount() {
		// TODO Auto-generated method stub
		return listCountry.size();
	}

	@Override
	public String getItem(int position) {
		// TODO Auto-generated method stub
		return listCountry.get(position);
	}

	@Override
	public long getItemId(int position) {
		// TODO Auto-generated method stub
		return 0;
	}

	public static class ViewHolder
	{
		public ImageView imgViewFlag;
		public TextView txtViewTitle;
	}

	@Override
	public View getView(int position, View convertView, ViewGroup parent) {
		// TODO Auto-generated method stub
		ViewHolder view;
		LayoutInflater inflator = activity.getLayoutInflater();

		if(convertView==null)
		{
			view = new ViewHolder();
			convertView = inflator.inflate(R.layout.gridview_row, null);

			view.txtViewTitle = (TextView) convertView.findViewById(R.id.textView1);
			view.imgViewFlag = (ImageView) convertView.findViewById(R.id.imageView1);

			convertView.setTag(view);
		}
		else
		{
			view = (ViewHolder) convertView.getTag();
		}

		view.txtViewTitle.setText(listCountry.get(position));
		view.imgViewFlag.setImageResource(listFlag.get(position));

		return convertView;
	}
}
main.xml
<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:orientation="vertical"
    android:layout_width="fill_parent"
    android:layout_height="fill_parent">

    <GridView
    	android:layout_height="wrap_content"
    	android:id="@+id/gridView1"
    	android:layout_width="match_parent"
    	android:numColumns="auto_fit"
    	android:horizontalSpacing="10dp"
    	android:verticalSpacing="10dp">
    </GridView>
</LinearLayout>
gridview_row.xml
<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout
	android:id="@+id/relativeLayout1"
	android:layout_width="fill_parent"
	android:layout_height="fill_parent"
	xmlns:android="http://schemas.android.com/apk/res/android"
	android:background="@drawable/border"
	android:padding="5dp">

    <ImageView
    	android:layout_height="64dp"
    	android:id="@+id/imageView1"
    	android:layout_width="64dp"
    	android:src="@drawable/icon"
    	android:layout_alignParentTop="true"
    	android:layout_centerHorizontal="true">
    </ImageView>

	<TextView
		android:text="TextView"
		android:layout_height="wrap_content"
		android:id="@+id/textView1"
		android:layout_width="wrap_content"
		android:layout_below="@+id/imageView1"
		android:layout_marginTop="2dp"
		android:layout_centerHorizontal="true"
		android:textSize="18sp"
		android:ellipsize="marquee"></TextView>


</RelativeLayout>

Download this example: https://github.com/PareshMayani/Android-GridView-Example
